SMT GPIO Header for Raspberry Pi HAT - 2x20 Short Female Header
This SMT (Surface Mount Technology) GPIO header provides an ultra-slim solution for Raspberry Pi HAT designs. The short female header maintains a low profile while still providing full 40-pin GPIO connectivity—ideal for custom PCBs where height is critical.
Designed for surface-mount soldering rather than through-hole, this header requires more careful installation but delivers the most compact form factor possible for HAT connections.
Key Features
- Surface Mount Design – SMT soldering for minimal height
- Short Form Factor – Lower profile than standard headers
- 40-Pin GPIO – Full 2×20 connection for all GPIO pins
- Lightweight – Only 2g for weight-sensitive applications
Specifications
- Configuration – 2×20 (40 pins)
- Type – Short female header, SMT
- Pitch – 2.54mm (0.1")
- Weight – 2g
Compatibility
- Raspberry Pi B+, A+, Pi 2, Pi 3, Pi 4
- Custom HAT PCB designs
Ideal For
- Custom ultra-slim HAT designs
- Space-constrained enclosures
- Production HAT manufacturing
- Low-profile Pi accessories
